Thermatouch Control Kit-Modern Recessed

Thermatouch Control Kit-Modern Recessed

from 1,289.00

A) Therma Touch Control

7” LCD screen that controls steam shower functions; with serenity, users can control light and sound’ Tranquility mode includes pre-programmed natural sounds with nine relaxing themes; includes built in Bluetooth, stereo audio output and Ethernet connection.

B) No Touch Steamhead

Whisper quiet retractable steamhead with integral aromatherapy well.

Group A Finish - Oil Rubbed Bronze, Polished Chrome, Polished Nickel, Satin Nickel

Group B Finish - Polished Brass, Antique Brass, Antique Copper, Antique Nickel, Black Nickel, Polished Copper, Polished Gold, Satin Brass, Satin Chrome, White

Finish Option:
Quantity:
sale
Add To Cart

SPECIFICATIONS – ThermaTouch Control

Construction.............ABS Injection molded plasticControllability......................Steam, Light & SoundAudio Out .................................. 1/8” Barrel Jack Power Supply................ThermaSol PDM (10-8147)Display ...................... 7” Wide LCD Touch Screen

SPECIFICATIONS – Aromatherapy Steam Head

Construction........................... 360 Half Hard Brass Aromatherapy............... .............Integral Reservoir Operation..........Thermal operated retractable outlet

Features:

  • Activate last showers settings

  • Turn Steam/Light/Music Systems: On or Off

  • Control lighting

  • Set Time and Temperature Volume settings

  • Tranquility Environment: Built-in Sound and Video

  • Bluetooth enabled

  • Stereo Audio output

Aromatherapy Retractable Steam Head:

  • Patented NoTouchTM retractable steam head withintegral Aromatherapy well

  • Available in 14 finishes

  • Sleek new design dispenses steam safely

  • Whisper quiet operation

Installation Notes:

  • Refer to ThermaSol installation Instructions Doc No. 81190 for complete instructions.

  • Requires wall cut out opening of 7-3/8” Wide X 5-3/8” High X 3-1/2” Deep.

  • Use Mud Ring for Tile installation and ThermaTouch Control placement (04-8544).

  • Ensure 3-1/2” clearance behind the rear of the control for cable clearance.

  • The steam head should be installed 12” inches from the floor and 6” from any wall. Locate as far as possible from the bathingseating area or location of the users and not below any fixtures.

Product Specification:

The ThermaTouch Control is a 7” LCD Touchscreen Control used to operate other ThermaSol modules such as Steam Room functions,Light, Sound and Tranquility Visualization, Stereo Audio output and Ethernet connection. The control is approx. 8-1/8” Wide X 6 – 1/8”High X 2 –1/2” Deep. It requires a wall cutout 7-3/8” Wide X 5-3/8” High and must have a clear in wall depth of 3-1/2”.

SPECIFICATIONS – Aromatherapy Steam Head Construction........................ 360 Half Hard Brass Aromatherapy......................... Integral Reservoir Operation..... Thermal operated retractable outlet

Contemporary – Modern Recessed – Traditional ‐ Regency

Aromatherapy Retractable Steam Head Basic Operation:

  • Patented NoTouchTM retractable steam head with integral Aromatherapy well

  • Available in 4 Styles and 14 Finishes

  • Sleek new design dispenses steam safely

  • Whisper quiet operation

Installation Notes:
The steam head should be installed 12” inches from the floor and 6” from any wall. Locate as far as possible from the bathing seating area or location of the users and not below any fixtures.

Product Specification:
The Steam Head shall be made from half hard Brass, includes the ability to open and close automatically and incorporates an Aromatherapy reservoir.
